ProScan H107 電動平台

產品服務專線：04-27080265 / 台中
02-89924292 / 台北

產品介紹

INTRODUCTION >> PRIOR H107

Designed to fit older generations of inverted microscopes, the H107 Inverted Stage incorporates Intelligent Scanning Technology (IST).

In conjunction with extensive testing, IST allows each stage to be pre-programmed with a unique set of operating characteristics particular to that stage to ensure optimum performance.

IST allows the ProScan™III controller to make any required adjustments to maintain superior orthogonality and metric accuracy.

Prior電動台系列產品可提供最長五年的原廠保固 (請來電洽詢)

產品特色

FEATURES >> PRIOR H107

適用於大多數知名的顯微鏡廠牌
解析精度小於 1 µm
移動行程範圍為 112mm x 70mm

產品規格

SPECIFICATIONS >> PRIOR H107

零件編號 Part Number	H107
XY重覆性精度 XY Repeatability	± 1.0 µm
最大荷重 Maximum Load	10 kg
最小寸動精度 Minimum Step Size	0.04 µm
最大行程範圍 Maximum Travel Range	112 mm x 70 mm
滾珠螺桿螺距 Ball Screw Pitch	2 mm
